BOX OVN BURN - WB53T10006

Replacement Parts

The replacement numbers for this part are: Turn gas off. Remove front door by pulling the lock covers back and pulling door up. Remove all cooking racks. Push back and lift enamel cover plate. Remove heat shield. Either use crosstip screwdriver or nutdriver (ratchet driver works as well, all the ovens have a different size nut/screw so check your size) and remove ignitor. Remove...Read moresmall shield and gas burner tube from pan. Remove all nut/screws from pan, lift up and pull towards front (ignitor can not go through pan) exposing electrical connector behind insulation. Disconnect and pull through pan. Replace pan (I had to replace older pan due to rust) and push connector from new ignitor through hole and connect to plug. Push pan in attach new ignitor (easier) to gas tube burner and place burner back through hole. Reattach shield and burner to tube to pan. At this point I tested the new ignitor which worked perfectly. Turn off oven. Place heat shield over burner tube. Replace enamal cover plate. Replace oven racks. Place door and lock holders on the hinges. Easy. BTW I am 70 and it took me just at 25 minutes with set up for tools, door, rack and enamel cover removal, heat shield removal and then the more labor intensive nut/screw removal, old ignitor and gas burner tube removal, pan removal, new ignitor replacement, new pan replacement, gas tube with shield attachment, heat shield attachment, enamel cover, grill racks and door attachment. Perfect parts fit well work well.Read less
