CUP FUNNEL FSD - WH03X27183

Replacement Parts

The replacement numbers for this part are: The impeller is not strong enough to clean the clothes. So, I replaced it with the agitator. They are interchangeable. BUT not easily. You have to remove the front panel of the washer. using a putty knife to release it at the top edge, by pushing in on both sides. If you know where to push in, it does come off easily. That allows you...Read moreto release the lid sensors on the left side. Clip the two zip ties, unscrew the two sensors. Then raise the top of the washer to allow insertion of the agitator. Otherwise, the agitator is too big to insert. Also, remove the two screws the hold that angled panel above the washer lid, so the agitator can has a little more room. The bolt that holds the impeller in place is the same one you can use to fasten the agitator. I think was about an 11mm hex head. Right hand threads. NOT left hand threads, when removing the impeller.Read less
